Conoma JXF-8000 RoHS 1.0 Testing Equipment
RoHS 1.0 Testing Equipment (Conoma JXF-8000) is the leading solution for hazardous substance inspection (Pb, Cd, Hg…) and high-precision coating thickness measurement. View full specs, features, and quotes here!
Product Information
RoHS 1.0 Testing Equipment Conoma JXF-8000: Comprehensive Hazardous Substance Inspection Solution
As international environmental protection standards become stricter, controlling hazardous substance content in products is mandatory for exporting enterprises. The RoHS 1.0 testing equipment Conoma JXF-8000 emerges as an optimal technological solution, helping businesses easily overcome strict technical barriers such as RoHS 2.0, Halogen-free, or California 65.
This article provides a detailed analysis of the features, technical specifications, and reasons why your business should own this high-end inspection equipment.
1. What Is The RoHS 1.0 Testing Equipment Conoma JXF-8000?
The RoHS 1.0 testing equipment Conoma JXF-8000 is a specialized Energy Dispersive X-ray Fluorescence (EDXRF) spectrometer. This device is designed for qualitative and quantitative analysis of hazardous chemical elements in materials, electronic components, plastics, and metals.
In addition to its primary function of environmental safety inspection, the machine integrates the capability to measure metal coating thickness with nanometer-level precision.
2. Key Applications Of The RoHS 1.0 Testing Equipment
Conoma JXF-8000 meets diverse inspection needs in modern industrial supply chains:
- RoHS & California 65 Screening: Rapidly detects strictly prohibited heavy metals and dangerous compounds including Lead (Pb), Mercury (Hg), Cadmium (Cd), Hexavalent Chromium (Cr VI), and brominated flame retardants (PBB, PBDE).
- Halogen-Free Testing: Accurately quantifies Chlorine (Cl) and Bromine (Br) content in printed circuit boards (PCBs) and polymer materials.
- Coating Thickness Measurement: Analyzes structures from 1 to 2 metal plating layers, inspecting surface coating thickness with a microscopic detection limit starting from just 0.005 µm.
- Alloy Composition Analysis: Determines the percentage composition of elements from Sulfur (S) to Uranium (U) in raw input materials.
3. Outstanding Technological Advantages Of Conoma JXF-8000
Premium US-made Si-pin sensor
The heart of the RoHS 1.0 testing equipment Conoma JXF-8000 is the premium Si-pin detector (X-123 DP5 FW6) imported from the USA. This component delivers extremely high energy resolution ( 145 ± 5 KeV ), cleanly separating the spectral peaks of elements with close wavelengths to minimize errors.
Smart analysis algorithms
The combination of the Empirical Coefficient Method and the Fundamental Parameter Method V1.0 allows the software to automatically process background noise. The machine delivers accurate quantitative analysis results even with complex sample shapes.
Smart chamber design with absolute safety
- Infinite sample size: Large standard sample chamber ( 420 x 320 x 65 mm ). Notably, the smart open-top design allows placing circuit boards or components of unlimited size for direct testing.
- Dual radiation protection: The intelligent protection system automatically cuts off X-ray emission as soon as the lid shows any sign of opening, ensuring 100% safety for operating technicians.
4. Detailed Technical Specifications
You can easily select, copy (Ctrl + C), and paste (Ctrl + V) this table directly into Excel:
| Parameter Name | Configuration Details |
|---|---|
| Analytical Element Range | From Sulfur (S) to Uranium (U) |
| Limit of Detection (LOD) | Pb <= 5ppm; Cd/Cr/Hg/Br <= 2ppm; Cl <= 50ppm |
| Signal Detector | Premium US Si-pin sensor (X-123 DP5 FW6) |
| Energy Resolution | 145 ± 5 KeV |
| Camera System | HD CCD 8 Megapixel |
| Filter System | 5 automatic switching composite filters |
| Collimator | Sizes from Phi 0.3mm to Phi 8mm |
| Measurement Time | From 10 to 200 seconds (adjustable) |
| Sample Chamber Size | 420 x 320 x 65 mm |
| Overall Machine Dimensions | 520 x 400 x 355 mm |
| Equipment Weight | 41.8 kg |
| Software Features | Empirical Coefficient Method & Fundamental Parameter Method V1.0 |
| Safety System | Dual Radiation Protection |
5. Why Should Businesses Choose Conoma JXF-8000?
Investing in the RoHS 1.0 testing equipment Conoma JXF-8000 helps businesses gain complete control over incoming and outgoing quality control (QC) phases. You no longer need to spend time and heavy expenses sending samples to external testing centers.
The included software supports the “Open Working Curve” feature, allowing engineers to add the factory’s own standard samples, optimizing accuracy specifically for the enterprise’s unique product lines.
